Stepper Motors
2S39A-038 Series
The 2S39A Series High Torque Stepper Motors offer a great value without sacrificing quality. These motors are designed to offer the highest possible torque while minimizing vibration and audible noise. A broad line of motor windings and stack lengths are available off-the-shelf, or the motors can be customized to fit your machine requirements.
See Kinco Stepper Driver section for compatible driver options.
- 39mm Frame Size
- 1.8° Step Angle
- High Torque - Up to 0.28 Nm
- High Step Accuracy and Resolution
- Low Vibration and Noise
- Shaft Flat as Standard
- Can be Customized for*
- Winding Current
- Shaft Options
- Cables and Connectors
- Encoders and Brakes
- CE Certified and RoHS Compliant
.png)
| Item ↑ ↓ |
Frame Size ↑ ↓ |
Bipolar Torque (Nm) ↑ ↓ |
Bipolar Current (A) ↑ ↓ |
Bipolar Voltage (V) ↑ ↓ |
Bipolar Inductance (mH) ↑ ↓ |
Rotor Inertia (g-cm²) ↑ ↓ |
# of Lead Wires ↑ ↓ |
Shaft ↑ ↓ |
Length (mm) ↑ ↓ |
Weight (kg) ↑ ↓ |
Price (USD) ↑ ↓ |
Quantity Discounts |
Stock Status ↑ ↓ |
Add To Cart |
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2S39A-038-007-4D | 39 | 0.28 | 1.10 | 4.4 | 23 | 24 | 4 | Double | 38.10 | 0.20 | $62.00 |
view here
|
2 in Stock |
|
||||||||||||||
| 2S39A-038-007-4S | 39 | 0.28 | 1.10 | 4.4 | 23 | 24 | 4 | Single | 38.10 | 0.20 | $62.00 |
view here
|
2 in Stock |
|
||||||||||||||
IMPORTANT NOTE: When stock status reads "contact us," the lead time could range from 6 to 16 weeks, model dependent. Please contact the factory for more details, or for a possible motor substitution.
- Dimensions
- Wiring Diagram
- Specifications
.png)
.png)
.png)
