K533 Analog IO Expansion

The PLC-K533-04IV Analog Input/Output Module was designed to do the job of both the PLC-K531 and PLC-K532 series all on one module. The PLC-K533-04IV is equipped with 2 analog inputs and 2 analog outputs. The PLC-K533-04IV performs a 12-bit conversion on the inputs for high-resolution measurement and can be configured to read voltages or currents of different ranges. The current ranges of the analog inputs are 0-20mA or 4-20mA, and the voltage ranges of the analog outputs are 1-5VDC or 0-10VDC. The analog outputs have a 12-bit output resolution allowing the user to increment in 976μV or 3.9μA steps. The current ranges of the analog outputs are; 0-20mA or 4-20mA. The voltage ranges of the analog outputs are 1-5VDC or 0-10VDC. The K533 series has an accuracy of ±0.5% to ensure a precise reading.




  • Current and Voltage Inputs
  • Current and Voltage Outputs
  • Provides Wide Input/Output Range
  • Up to 6 Analog Input/Output Modules in One PLC-K5 System
  • 12-bit Conversion for High-Resolution Measurement
  • Very Reliable ±0.5% Error

Item
↑ ↓
Module
Type
↑ ↓
Input
Points
↑ ↓
Output
Points
↑ ↓
Input
Type
↑ ↓
Output
Type
↑ ↓
Downloads Price
(USD)
↑ ↓
Quantity
Discounts
Stock
Status
↑ ↓
Add To
Cart
K533-04IV Expansion Module,
Analog I/O
2 2 0-20mA
4-20mA
1-5VDC
0-10VDC
0-20mA
4-20mA
1-5VDC
0-10VDC
Click here for PDF Spec Sheet Click here to request a Quote. $119.00 view here
Quantity Discounts
1pc. $119.00
10pc. $115.32
25pc. $111.98
50pc. $103.50
100pc. $94.96
Contact Us for Quantities over 100
7 in Stock Add to Cart

IMPORTANT NOTE: When stock status reads "contact us," the lead time could range from 6 to 16 weeks, model dependent. Please contact the factory for more details.

  • Dimensions
  • Wiring Diagram
