FD122-CA-000

The FD122-CA-000 Servo Drive is a great fit for applications requiring position, speed, and/or torque control methods. The uniqueness of this servo drive package is the flexibility of using a single servo drive that can accommodate motors with power ratings ranging from 50-200W. Also, it is designed to switch dynamically among different control methods for more flexible operation. The FD122-CA-000 Servo Drive can operate position control mode either with pulse and direction inputs, 8 internal position points, or 8 internal speed points. The FD122-CA-000 Servo Drive operates with 24-70DV input. These drives come standard with an RS232 which can be operated using MODBUS Protocol, a CAN BUS port to be operated using CANopen Protocol, or can be operated using our Free, Easy-to-Use Software. Please consult our Application Engineers for more information.

Note:FD122-CA Series Servo Drives have been discontinued and are LTSOH (Limited to Stock on Hand).




  • 24-70VDC
  • 50-200 Watt Power Range
  • Position, Speed, and Torque Control
  • RS232 and CAN BUS Port
  • MODBUS and CANopen Standard
  • Requires 2500PPR Encoder Input
  • Communication Software
    • Configure Parameters
    • I/O Signal Monitoring
    • Speed and Position Curves
    • Gain Adjustments
  • Programmable Inputs and Outputs
    • 4 Inputs
    • 2 Outputs
  • CE Certified

Item
↑ ↓
Rated
Power
(Watts)
↑ ↓
Rated
Voltage
↑ ↓
Drive
Control
Capabilities
↑ ↓
COMM
↑ ↓
I/O
Signals
↑ ↓
Downloads Price
(USD)
↑ ↓
Quantity
Discounts
Stock
Status
↑ ↓
Add To
Cart
FD122-CA-000 50-200 24-70 VDC Position,
Speed, Torque
CANopen 4 Inputs
3 Outputs
Click here for PDF Spec Sheet Click here to Download Software Click here to request a Quote. $254.00 view here
Quantity Discounts
1pc. $254.00
10pc. $244.15
25pc. $236.77
50pc. $221.80
100pc. $206.10
Contact Us for Quantities over 100
5 in Stock Add to Cart

IMPORTANT NOTE: When stock status reads "contact us," the lead time could range from 6 to 16 weeks, model dependent. Please contact the factory for more details.

  • FD122 Dimensions
  • X3 Connector Pinout
